HUNSN 12.1″ TFT XGA LED Industrial Panel PC, 10 Point Projected Capacitive Touch Screen, Intel Core I5, NPW19, Front Panel IP65, VGA/HDMI/2COM, (Barebone, NO RAM, NO Storage, NO System)

$576.00

12 inch tft xga led industrial grade front panel ip65 touch panel pc. 10 points projected capacitive touch screen, typical 1024*768 resolution.Powered by intel core I5 gen. 3th processor, ideal for industrial and commercial applications.
Barebone is no RAM,no SSD, no HDD and as well no any system. you have to insert RAM and SSD(SSD+HDD) on your own. Hardware could be compatible with windows/linux distributions.
Low power consumption, low heat, use dedicated turbo silent cooling fan to ensure long-term operation and stable heat dissipation
HUNSN NPW19 designed with 2*rs232+ vga+hdmi+ lan+ 2*usb2.0+ 2*usb3.0+ dc+ audio in&out, support automatically power on after power failure, size at 392.4*313.6*54.9mm, 4kgs, 12v5a power supply, with power cord, make sure to use big brand memory and ssd/hdd with quality assurance.

SKU: 9SIAK3UJA76618 Category:
Add to Wishlist
Add to Wishlist

Model Number: HUNSN NPW19
Panel Specification: 1. Industrial 12.1″” TFT XGA LED Panel
2. 10 Point Projected Capacitive Touch Screen
3. Front Panel IP65
Chassis: Aluminum
CPU: Intel Core I5 Gen. 3th CPU, ship any one of them
Memory: SO DIMM 1* DDR3L 1333/1600, Max. 8G RAM
Storage: 1* mSATA SSD+ 1* 2.5 Inch HDD
I/O: 2*RS232+ VGA+ HDMI+ LAN+ 2*USB2.0+ 2*USB3.0+ DC+ Audio in&out
Cooling System: With fan
BIOS: Support Diskless Start, Wake-Up on Lan, Call Boot (Power On Boot), Watchdog and Other Functions
Network: Realtek 8111E
Audio: ALC662
Physical Dimension: 392.4*313.6*54.9mm
Gross Weight: 4KGS
Opening Hole Size: 311* 240mm (L*W)
Installation Method: Standard VESA screw hole (75*75 or 100*100mm) for flexible installation
Embedded (Recommended)/Wall-mounted/Desktop/Cantilevered/Other Installation Methods
Display Parameters:
Resolution: 1024*768
Perspective: 80 (left), 80 (right), 80 (up), 80 (down)
Lumen (cd/m2): 400
Contrast: 800
Backlight Life: 30,000 hours (Min.)
Touch screen:
Transmittance: 86±5% at 550 nm wavelength
Controller: USB
Durability (number of touches): 200 million
Operating Temperature: 0 ~ 50°C with SSD,0 ~ 40°C with HDD
Storage Temperature: -20 ~ 60
Operating Humidity: 10% ~ 95% @ 40 without condensation
Power Supply: DC100-240V AC/50-60Hz, 12V5A
Packing List: HUNSN NPW19 Panel PC+ Power supply+ Power Cord+ Embedded Buckle Kit+ Warranty Card
System Support: Windows 7/10,Linux Ubuntu etc

ATTENTION: Barebone System,N/A Operating System, thank you.

Brand

HUNSN

color

Black

CPU ItemType

Intel Core i5 3rd Gen

North Bridge

Intel SoC

Date First Available

20-May-22
